KD-295A IGBT Inverter MMA or Stick Welding Machine IN-225/255/275/295A1/A2/B1/B2

Zhejiang Kende Mechanical & Electrical Co., Ltd. Home / Product / IGBT Inverter MMA or Stick Welding Machine / KD-295A IGBT Inverter MMA or Stick Welding Machine IN-225/255/275/295A1/A2/B1/B2

KD-295A IGBT Inverter MMA or Stick Welding Machine IN-225/255/275/295A1/A2/B1/B2

●Hot Start lets you start welds easily

●ARC Force monitors the voltage and provides additional current when needed

●Anti-stick technology allows the user to easily separate the electrodes from the workpiece

●Power Switch lights up to tell you the power is on

●Thermal overload protection with indicator light

●2m welding cable with dual-angle electrode holder

●1.5m ground cable with clamp

●High welding current stability for consistent output

●DC current out provides stable output for good penetration

CONTACT US Zhejiang Kende Mechanical & Electrical Co., Ltd.

Technical Characteristics

●Use powerful IGBT switched and advanced inverter control technology

●Use PWM control technology and Constant Current (CC) output control, welding current can Be exactly controlled & adjust continuous in large scale.

●Work properly under 140-580V.

●Excelient arc characteristics and welding performance.With Anti-stick, hot start , arc force .

●Moisture- proof, anti- corrosion, anti-vibration, and anti-conductive dust

●Small size, light-weight, low power consumption, energy saving up to 30%

●With auto-protection functions of over-current and over-heat.

●Be able to weld all kinds of metal, such as carbon steel, alloy steel, cast iron, stainless steel, etc.

Specifications

Rated
Supply
Voltage
Supply
Frequency
Rated
Input
Capacity
Rated
Supply
Current
No-Load
Voltage
Welding
Current
Range
Welding
Current
Max
Rated
Welding
Voltage
Rated
Duty
CYCLE
Usable
Electrode
Efficiency Power
Factor
Degrees of
Protection
Class of
Insulation
Net
Weight
Machine Size
Technical Characteristics

V

Hz

KVA

A

V

A

A

V

%

mm

%

Cosφ

IP



kg

mm

KD-295A 230V 50/60 7 41.5 86 20-200 250 28 40 1.6-5 85 0.9 IP21S H 4.5 275*130*215
