Advanced inverter and microcomputer control technology; Over-heating, over-current, under-voltage and over-voltage protection control function;Current or wire feed speed display meter, A and m/min LED;Voltage display meter and V LED at front panel ; Easy to install welding wire
Technical Characteristics
●Use powerful IGBT switches, advanced inverter and control technology.
●Microprocessor control technology.Constant voltage (CV) and current (CC) output control.
●MIG/MAG(GMAW), Flux cored (FCAW) and MMA or Stick(SMAW) welding processes.
●2T, 4T and VRD mode.VRD under MMA or Stick(SMAW).2T, 4T mode under MIG/MAG(GMAW) and Flux cored (FCAW).
●Can weld all kinds of metal, e.g.stainless steel, carbon steel, etc.
●Excellent arc characteristics.Good welding performance and little spatter.
●With two gun switch optional models of 2T and 4T.
●Auto protection functions of over-current and over-heat.
●High welding speed and duty cycle.
●High quality and energy savings up to 30℅.
Specifications
Rated Supply Voltage |
Supply Frequency |
Rated Input Capacity |
Rated Supply Current |
No-Load Voltage |
Welding Current Range |
Rated Welding Voltage |
Rated Duty CYCLE |
Usable Wire |
Efficiency | Power Factor |
Degrees of Protection |
Class of Insulation |
Net Weight |
Machine Size | |
Technical Characteristics |
V |
Hz |
KVA |
A |
V |
A |
V |
% |
|
% |
Cosφ |
IP |
|
kg |
mm |
NBC-200SI | 1~220/230V | 50/60 | 8.3 | 38 | 51 | 40-200 | 24 | 30 | 0.8-1.0 | 85 | 0.9 | IP21S | H | 15 | 270L 260W 430H |
NBC-270SI | 3~380 | 50/60 | 10 | 15 | 51 | 40-270 | 27.5 | 40 | 0.8-1.2 | 85 | 0.9 | IP21S | H | 16 | 270L 60W 430H |
